Product ID: DM-5025, DM-5030, DM-5230, DM-5250, DM-6055, DS-4530, DS-5030, DS-5530, SM-73BP, SM-7338


D.C. Motor, Portable Bag Closer Motors, AC Commutator Motors


This series of motors are: D.C. Motors, D.C. Reduction Gear Motors, A.C. Commutator Motors, Portable Bag Closer Motors, Speed Controller & Drives.
DC Motor:
  1. DM series: This standard model has five styles, output 15W-250W, speed: 2,000RPM & 3,200RPM. Welcome to selection.
  2. DS series: This is custom made item. The design can be changed according to the customer's damand in order to fit any powers on the machine or on the special machine of gearing. There are 900RPM to 6,000RPM of speed to selection.

DC Gear Reducer Motors:
There are five models, 15/25W, 25/40W, 30/50W, 60/100W, 100/150W. These models can be used on six kinds of reduction gear heads. They can lower the speed and increase the torque.
AC Commutator Motors:
It suitable for any machines of high speed, output: 100-150W, speed: 18,000RPM.
Portable Bag Close Machine Motors:
They are suitable for Japan, U.S.A., Taiwan and other countries who make the portable bag close machine.
The Above Motors: can be extra an electromagnetic brake or variable speed controller to make it as a break motor or variable speed motors.
click on the photo to close this window

Click here for details.

Specifications:


  • Rated Voltage: 12, 24, 48, 90, 180VDC
  • Output Power: 15W~250W
  • Torque: 1kg-cm ~ 10kg-cm
  • Speed:
    • DC Motor: 900RPM~6,000RPM
    • AC Commutator Motor: 8,000RPM~18,000RPM
  • Insulation Grade: Grade F (155°C)
  • DM Series: DM-5025, DM-5030, DM-5230, DM-5250, DM-6055
  • DS Series: Custom Made Item, used on many kinds of machine.
  • SM Series: SM-73BP, SM-7338
  • FM Series: DC 4 Pole Motors
  • DM Series (Model of DC Gear Reducer Motors) showed in the table.

Features:


  • Can be C.W. & C.C.W., starting torque hi, compact in size, speed control easy.
  • Sample purchase.


Model Power Speed Flange Dimension (L x W) Fit Gear Head
DM-5025 15/25W 2,000/3,200RPM 70mm x 70mm 3GN
DM-5030 25/40W 2,000/3,200RPM 80mm x 80mm 4GN
DM-5230 30/50W 2,000/3,200RPM 90mm x 90mm 5GN
DM-5250 60/100W 2,000/3,200RPM 90mm x 90mm 5GN/5GU
DM-6055 100/150W 2,000/3,200RPM 90mm x 90mm 5GU


Ordering information:

  • Minimum Order: Negotiable
  • OEM/ODM Product
  • Branded Product
  • Buyer's Label Offered

  • TEL: 886-2-2989-0399

  • FAX: 886-2-2989-2358/2988-3652
